Matek’s latest HEX-PDB is capable of handling high power draws necessary to push UAV’s or X-Class drones. Capable of providing power for a hexacopter or quad this PDB is capable of handling 140A continuous current and 264A burst current.

Has both 30×30 and 20×20 mounting patterns.

PDB-HEX 12S PDB
      • Input voltage range: 6~60V (2~12S LiPo)
      • PDB/current sense resistor: 140A cont, 264A burst
      • ESC power pads: 60A cont. 100A burst
      • 6 x ESC power / signal / telemetry pads
      • Current Senor: 264A, 3.3V ADC
      • Current Scale 125(INAV/BF), BATT_AMP_PERVLT 80 (ArduPilot)
JST-SH-8P Connector and Pads
      • Vbat: Battery voltage
      • G: Ground
      • Curr: Current signal
      • Tlm: Duplicates Tlm pads for ESC telemetry
      • ESC Signal: S1/S2/S3/S4/S5/S6
      • Vx: Regulator output
BEC Vx Output (5V default)
      • Vx: 5V by default, Continuous 5 Amps
      • Bridge 9V jumper, Vx= 9V, Continuous 4 Amps, Max.5A
      • Bridge 12V jumper, Vx= 12V, Continuous 4 Amps, Max.5A
      • Output Short-circuit tolerant (1 seconds)
      • Overcurrent protection & self-recovery
Voltage Divider
      • 1K:20K resistors
      • Output 1/21 Vbat voltage
Physical
      • Mounting: 30.5 x 30.5mm, 20 x 20mm, Φ3mm
      • Dimensions: 49 x 40 x 6 mm
      • Weight: 12g
Including
    • 1 x PDB-HEX
    • 1 x Rubycon ZLJ 63V 390uF
    • 1 x JST-SH 1.0_8pin cable, 5cm
    • 2 x JST-SH 1.0_8pin connectors
