Matek BEC12S-PRO

AVAILABILITY: In Stock (4 items)

$28.80

4 in stock

or 6 weekly interest-free payments from $4.80 with Laybuy what's this?

  •  Delivery & Return

    Domestic Shipping

    • Estimate Domestic delivery options can be calculated at the Shopping Cart.
    • Home delivery orders are delivered on weekdays by Australia Post.
    • 4 - 7 business days for delivery to metro locations.
    • 7 - 10 business days to regional locations including WA, QLD and NT.
    • This delivery time frame is subject to changes in circumstances.
    • All orders dispatched within 2 to 3 business days.
    • See the Delivery Policy for details on shipping methods, costs and delivery times.

    International Shipping

    • Estimate International delivery options can be calculated at the Shopping Cart.
    • International Orders will be shipped via Australia Post.
    • Any customs or import duties and associate fees may impose on your destination country.

    Returns And Exchanges

    • Replacemnet warranty only cover for items that are Dead On Arrival (DOA).
    • 7 days return policy for all unopened items.
    • See conditions and procedure in our Returns Policy.
  •  Ask a Question

  Share

The MATEKSYS BEC12S-PRO features a wide 9-55V Operating Input Range, 3x Output Voltage Options 5V/8V/12V and supports continuous output current of up to 5A, peak current of 9A. This voltage regulator also features a synchronous switching step-down (buck) regulator, thermal Shutdown, output Short-circuit tolerance (2 seconds), overcurrent protection & self-recovery and much more!

BEC12S-PRO

  • Wide 9V to 55V Operating Input Range with TVS protection
  • 3x Output voltage options,  5.2V, 8V or 12V. Default 5.2V.
  • Synchronous switching step-down (buck) regulator with typical efficiencies of 88% to 96%
  • Supports continuous output current of up to 5A, peak current of 9A.
  • Output ripple  30mV (VIN=50V,  Output 5.2V @ 5A), 60mV (VIN=50V, Output 12V @ 5A)
  • Standby current: 5~10mA
  • No reverse-input voltage protection
  • Thermal Shutdown
  • Output Short-circuit tolerant (2 seconds)
  • Overcurrent protection & self-recovery
  • Dropout voltage: 2V (Input>=14V is required for stable 12V output)
  • Pins distance: 3.81mm
  • Size & Weight: 35 x 24 x 5.5mm, 5g

Includes

  • 1pc/package
