RadioMaster RP4TD ELRS 2.4GHz Receiver
AVAILABILITY: In Stock (4 items)
$42.70
Brand: RadioMaster
4 in stock
Discover the RadioMaster RP4TD ELRS 2.4GHz Receiver, a cutting-edge solution for drone and fixed-wing model enthusiasts. With its advanced dual-channel design, exceptional signal sensitivity, and built-in WiFi for easy firmware updates, the RP4TD stands out as a top choice for reliable performance and versatility in any application requiring a serial receiver.
Features
- Gemini mode compatible
- Reliable DCDC Power supply circuit
- Class leading SNR and RSSI performance
- Optimized PCB design for better heat dissipation
- Upgraded antenna with greater durability and performance
- UART pads for extended applications
- Dual TCXO (temperature compensated crystal oscillator)
- 2x 100mw RF Telemetry power output
- Compatible with all 2.4GHz ExpressLRS modules and transmitters with built in 2.4GHz ExpressLRS
RP4TD ExpressLRS 2.4GHz Diversity Receiver
- Type: ISM
- MCU: ESP32
- RF Chip: SX1281 x 2
- Antenna: 65mm 2.4GHz T Antenna x 2
- Frequency Range: 2.4GHz
- Maximum Refresh Rate: 500Hz / F1000Hz
- Telemetry RF Power: Max 2x 100mW
- Working Voltage: DC 4.5-12.0V
- Weight: 1.4g (without antenna)
- Dimension: 23.7*16.3*4.0mm
- Firmware Version: ExpressLRS V3.3.0 pre-installed
- FW Target: RadioMaster RP4TD 2400 RX
- Bus interface: CRSF
- Extend interface: UART
