    Diatone Mamba Toka 1103 - 10000KV Motor

    Diatone Mamba Toka 1103 - 10000KV Motor


    Ask a Question


    The Mamba Toka 1103 Motor is a new series of motors by Diatone that is best suited for CineWhoops, like the Diatone MX-C Taycan or any 3″-4″ builds! Choose between two KVs to best fit your FPV needs: 8500KV or 10000KV.

    MAMBA TOKA 1103 10000KV Racing Motor
    • Overall Dimension: Φ14.8×9.8mm
    • prop mounting shaft diameter: 1.5mm
    • Installation hole position: 9×9mm, M2
    • Prop: 1.6inch ~ 3inch
    • Bearing: 4*1.5*2
    • Shaft Diameter: 1.5mm
    • Lead Wire Size: 24AWG × 100mm
    • Configuration: 9N12P
    • Magnet Wire: Class H, 240℃ Enameled Wire
    • Stator Diamter: 11mm
    • Stator Height: 3mm
    • Rated Voltage: 2S (8.4V)
    • Peak Current: 8.6A
    • ldle Current: 4V/0.5A
    • Maximum Power: 70W
    • Internal Resistance: 158Ω
